Metso Belt Cleaner - Belt Scraper

Belt Cleaner is a scraper for the conveyor belts which are used to transport raw materials in ironworks industry, mining, power stations and so on.

Necessity of Belt Cleaner
After conveying raw materials to next process, fine powders and mud often remain on the surface of belt conveyor. These cause many problems of adhesion to peripheral equipments, meander of belts, falling products and deterioration of work environment. By fixing these problems, we can expect prolonging life of belt conveyor, improvement of work environment, effective utilization of resources and cost reduction.

Characteristics

We scrape roughly ca. 90 % of transfer products by Pre-Cleaner, and we can scrape much effectively by adding T-Cleaner.

Product lines

Pre-Cleaner(Primary Cleaners)

●ABC70 For mining and aggregate industry. (for wet products),
Pulley diameter Φ350〜Φ600
●ABC90 For mining and aggregate industry. (for dry products),
Pulley diameter Φ350〜Φ600
●ABC95 For sawmill, Pulley diameter Φ350〜Φ600


T-Cleaner (Secondary Cleaners)

●HMS(RU) Rubber specification, standard type
●HMS(PU) Urethane specification, adherence prevention type

Characteristics

Pre-Cleaner(Primary Cleaners)

  • It has excellent abrasion resistance and uses polyurethane blades which are friendly to conveyor belts.
  • It always keeps optimum surface pressure by spring-tensioned structure, and there are no needs of troublesome tension adjustment.
  • It can be replaced safely in short time by aluminum cassette system.

T-Cleaner (Secondary Cleaners)

  • It uses super hard chip for blade material which is excellent of abrasion resistance, long life and low running cost.
  • It always keeps optimum surface pressure by spring-tensioned structure, and there are no needs of troublesome tension adjustment.
  • Tensioner can be set on both of inside and outside of shoot. It’s easy to select space for setting.
  • It can be replaced safely in short time by aluminum cassette system.
