Dust sealing refurbish field circumstance onsite and prevent from dust generating as same as noise-abatement measure.
- It can be adapted for all dust discharging facilities.
- A noise level can be decreased 10 or more db.
- Since attachment, removal, and adjustment are easy so that control of the process, management or repair of the covered machine and preservation work can be done easily.
![](images/dust/i_dust.gif)
![Sealing place and parts](images/dust/corner_title_02.gif)
■Dust sealing cloth
Application | No. | Color | Thickness | Width | Length | Temperature range |
General | No.1414 | black | 2mm | 1,350mm | 20m | -40〜+50°C |
Resistance to flame | No.1518 | black | 2mm | 1,350mm | 20m | -30〜+80°C |
Heat resistance | No.4896 | black | 2mm | 1,350mm | 20m | MAX135°C |
Electrostatics for 105![]() |
No.554 | black | 2mm | 1,350mm | 10m | -30〜+70°C |
■Grip
Product No. | Pars convolute radius | Length | Usage part | Mounting angle |
Grip strip No.14 | ー | 1,350mm | straight part | ー |
Grip corner No.14-55H | 55mm | 一辺205mm | outside control | 60°〜140° |
Grip corner No.14-55HI | 55mm | 一辺205mm | Inner side | 60°〜140° |
Grip corner No.14-55V | 55mm | 一辺205mm | perpendicular | 75°〜115° |
